Application

Network data transmission, surveillance video, computer room construction and other high-bandwidth system signals, including IEEE802.3AB 10G (ten gigabit Ethernet), TIA / EIA 1000Base-TX, 622 Mbit/s ATM, and any application system for ten gigabit cabling.

Characteristic

Super six network cable, also called 6A network cable, is a hair line specified in ANSI / TIA-568C, 2 and ISOIEC11801 super six soft / EA. It can support the same as 10 trillion, the maximum energy can reach 500 MHZ, at present, 6A is divided into non-shielding and shielding re-type, GA Lu shielding in the shape of the attenuation of the signal of the changing end of the layout.

Description

◆ Conductors are isolated by a single bare copper wire

◆ polyethylene insulated

◆ PE skeleton

◆ Shielding type for each pair of separate aluminum foil shielding

◆ can choose tear rope

◆ woven mesh shielding, ground wire environmental protection polyvinyl chloride sheath (optional flame retardant, LZSH, outdoor waterproof and other materials)

◆ working temperature: -40~60℃
