Application

Network data transmission, monitoring machine, machine room construction and other high system signals, including for IEEE802.3AB 10008unaT (dry water to the building). TAFA 1000Base-TX, 622 Mbit/s ATM, and any application system for six-class cabling.

Characteristic

Six types of 4 pairs of shielding cable is a kind of high quality products, through aluminum foil (woven net shielding pressure to provide good shielding effect, suitable for a variety of complex harsh electromagnetic environment places. It can be used together with the other six types of products to bring excellent network performance for users. There are four pairs of six types of cables, which are the solid core planning of 23 AWG regulations, and have CM, CMR fire protection standards, low smoke halogen free (LSZH) available. The product is used for horizontal wiring. Six class 4 pairs of cable center fillings can provide excellent crosstalk isolation function to ensure good performance. This unique production process maximizes performance and Yao connection function. The cable uses high-density polyethylene insulation, which is used for wiring systems in buildings that need to meet the wiring requirements.

Description

◆ Conductor using a single bare copper wire

◆ polyethylene insulation

◆ PE skeleton isolation

◆ optional tear rope

◆Polyester film, aluminum foil coating, woven mesh shielding, ground wire

Environmental protection polyvinyl chloride sheath (flame retardant, LZSH, outdoor waterproof materials can be selected)

◆ Operating temperature: -20~60℃
