Application

High-bandwidth system signals such as data transmission, surveillance video, and computer room construction, including IEEE802.3AB 1000Buse-T (Gigabit Ethernet), TIA / EIA 1000Base-TX, 622 Mbit/s ATM, and any application system for six-class cabling.

Characteristic

Six types of 4 pairs of cables is a kind of high quality products, can be used with other six types of products, for users to excellent network health. There are four pairs of six types of electric bodies, solid core insulated copper wire of 23 AWG wire gauge, and CM, CMI fire standard, low smoke no halogen [LSZH] available. The product is used for horizontal wiring. Six class 4 pairs of cable center fillings can provide excellent crosstalk isolation function to ensure good performance. This unique production process maximizes the performance and functionality of the cable using high-density polyethylene insulation for the wiring systems of buildings that need to meet the wiring requirements.

 Description

◆ Conductor using a single bare copper wire

◆ polyethylene insulation

◆ optional tear rope

◆ PE cross skeleton isolation

◆ Environmental protection PVC sheath (flame retardant, LZSH, outdoor waterproof and other materials)

◆ Operating temperature: -20-60℃
