Characteristic

◆ Fill: cotton yarn

◆ Conductor: using multiple 0.08mm 4N grade anaerobic copper stranded

◆ Cadding: non-woven fabric

◆ Insulation: mixed TPEE (monochrome code & color) ◆ shield: aluminum foil + tinned copper woven ◆ core number: 2~40 cores

◆ External quilt: special PUR material

◆ Conductor square number: 0.15~1.5mm² rated voltage: 300 / 300V

◆ External color: green, black

◆ Long-term permissible working temperature: fixed installation (-50~ + 125℃); mobile installation (-35~ + 125℃)

Minimum bending radius: fixed installation, bending radius of 6 D; moving installation, travel <10 m, the bending radius is 10 D; travel 10 m, the bending radius is 12 D

◆ Product characteristics: halogen-free, environmental protection, oil resistance, corrosion resistance, wear resistance, bending resistance, acid and alkali resistance, high elasticity, anti-interference (shielding type) and other characteristics are suitable for computer system, electronic equipment control, industrial electronic system, data transmission system and other occasions, can be used for fixed laying and mobile wiring

Testing

Test voltage: 1500V, 2000V

Flexible test: moving speed to bend various conditions in the tow chain, fixed in the standard way, bending radius r=6D, s=600mm, speed =90 times / min; moving speed: overhead speed 3 m/s, sliding speed 2 m/s, more than 30 million times. Insulation sheath performance test: according to the corresponding standard performance of the material.
