Characteristic

Conductor: using multiple 0.08mm 4N grade anaerobic copper stranded

Fill: cotton yarn ◆ coating layer: non-woven fabric

· Insulation: Special mixed PVC material (monochrome code & color) ◆ cores: 2~40 cores

◆ Shield: aluminum foil + tinned copper woven ◆ external quilt: modified PVC material

◆ Conductor square number: 0.15~1.5mm²◆ rated voltage: 300 / 300V

◆ External color: green, black

◆ Long-term permissible working temperature: fixed installation (-30~ + 105℃); mobile installation (-20~ + 105℃)

Minimum bending radius: fixed installation, bending radius is 6 D: mobile installation, travel <10 m, bending radius is 10 D; travel 10 m, bending radius is 12 D

◆ Product characteristics: environmental protection, oil resistance, corrosion resistance, wear resistance, bending resistance, anti-interference (shielding type) and other characteristics

Suitable for computer system, electronic equipment control, industrial electronic system, data transmission system and other occasions, can be used for fixed laying and mobile wiring

Testing

Test voltage: 1500V, 2000V

Flexible test: moving speed simulation for bending and moving conditions in the tow chain, fixed in the standard way, bending radius r=6D, s=600mm, speed =90 times / min; moving speed: overhead speed 3 m/s, sliding speed 2 m/s, more than 18 million times. Insulation sheath performance test: according to the corresponding standard performance of the material.
