Characteristic

◆ Conductor: using multiple 0.08~0.10mm 4N grade anaerobic copper stranded into ◆ filling: cotton yarn

◆ Cadding: non-woven fabric

◆ Insulation: special mixed PVC material

◆ Shielding layer: aluminum foil + tinned copper woven ◆ core number: 2~40 core ◆ conductor square number: 0.15~4mm²

◆ twisted: core 2 core twisted, all wire twisted cable ◆ core wire color: color or monochrome code ◆ sheath: special mixed PVC material

◆ Conventional sheath color: black fog surface ◆ rated voltage 300 / 300V

◆ Long-term permissible working temperature: fixed installation (30~ + 105℃); mobile installation (-20~ + 105℃)

◆ Minimum bending radius; fixed installation, bending radius is 5 D; moving installation, travel <10 m, bending radius is 7.5 D; travel 10 m, bending radius is 10 D

◆ Product characteristics: environmental protection, oil resistance, wear resistance, bending resistance, high flexibility, anti-interference and other characteristics

 Testing

Voltage test: 2KV/5min(10A)(AC)&1.5KV/5min or 2000V / 5min (10A) (AC)

Flexible test: movement speed simulation in the drag chain test from the finished product, fixed in the standard way, the bending radius, [m7.5D, sm600mm, speed m90 back / min; moving speed: overhead speed 3 m/s, sliding speed 2 m/s, over 10 million times, insulation sheath performance test: according to the material corresponding standard performance.
