Characteristic

 ◆ Fill: cotton fried

 ◆ Conductor: using 0.08mm 4N most anaerobic copper stranded

 ◆ Clad layer: no young cloth

 ◆ Pigeon green: a special TPEE mixture

 ◆ Shielding layer: color foil + filled copper weaving ◆ mushroom feet: 2~40m

 ◆ Core wire color: color

 ◆ Conductor square number: 0.15 mmm ²◆ conventional sheath color: black fog surface ◆ egg protection: special PUR department ◆ Shun house voltage 300 / 300V

 ◆ Long-term permissible working temperature: fixed installation (-50~ + 125℃); mobile installation (35~ + 125℃)

 ◆ Small bending radius: fixed installation, bending lifting diameter is 6.5 D; mobile installation, travel <10 m, the bending radius is 7.5 D travel 10 m, the bending radius is 10 D

 ◆ Product characteristics: environmental protection, halogen free, cold resistance, oil resistance, heat resistance, bending resistance, acid and alkali resistance, shoulder corrosion resistance, high elasticity, anti-interference and other characteristics

Testing

Voltage test: 2KV/5min(10A)(AC)&1.5KV/5min or 2000V / 5min (10A) (AC)

Backway test: moving speed simulation in the drag chain from the finished product resistance rod, fast standard way fixed, bending radius ra7.5D.s=600mm. Speed =90 round / min; moving speed: overhead speed J m/s. Slide base 2 m/s, J 0 million above. Insulation sheath performance test: according to the corresponding standard performance of the material.
