Characteristic

◆ Conductor: Made of multiple 0.08mm 4N grade oxygen free copper twisted together ◆ Filling: Cotton yarn

Insulation: special TPEE mixture ◆ Coating layer: non-woven fabric

◆ Number of cores: 2-40 cores ◆ Shielding layer: None

◆ Square number of conductors: 0.15-4mm ²                   ◆ Core wire color: colored

◆ Sheath: special PUR material ◆ Conventional sheath color: black matte surface

◆ Rated voltage 300/300V&300/500V

Long term allowable working temperature: fixed installation (-50~+125 ℃); Mobile installation (-35~+125 ℃)

◆ Minimum bending radius: fixed installation, with a bending radius of 6.5 × D;    Mobile installation with a bending radius of 7.5 when the stroke is less than 10 meters × D;    When the stroke is ≥ 10 meters, the bending radius is 10 × D

Product characteristics: Environmental protection, halogen-free, cold resistance, oil resistance, wear resistance, bending resistance, acid and alkali resistance, corrosion resistance, high elasticity, etc

Testing

Electric test: Z8V/5min (10A) (AC)&1.58V/5min Blue 2000V/5min (10A) (AC)

Quti test: The movement speed model is tested in the ground chain, and various conditions are adjusted. Samples are taken from or within the product, and the electricity is collected according to the process. Qiqu Morning Trail=7,50. s=500mm, flux=90 genera/min; Mobile speed: the idle speed is 3m/5, and the leakage of liquid is 2m/. More than 50 million times.

Pre qualification testing for ground green protection: Apply according to the corresponding material standards.
