Characteristic

Number of ◆ cores: 1 core

◆ Conductor: made of multiple tin-plated copper stranded

◆ color: color

◆ insulation:PVC

◆ External quilt: natural nylon ◆ shield: tin copper ◆ flame retardant: VW-1

◆ Rated voltage: 300 / 500V 450 / 750V ◆ Operating temperature: -65~ + 105℃

◆ Applicable: widely used in aircraft low-voltage line, highway monitoring equipment line installation, highway inductive coil special line.◆ Product characteristics: wear resistance, cold resistance, waterproof, oil resistance (gasoline mixture, etc.), not easy to burn, anti-aging, environmental protection and other characteristics ◆ Implementation standard: JB / T10261-2001 "Rated voltage 450 / 750V and below concentrated vinyl insulation nylon sheathed wire and cable"

Advantage

Nylon sheath line is widely used in aircraft low voltage line, highway monitoring equipment line installation, highway with inductive coil special wire (electronic police wire, inductive coil wire) is also used for lighting lamp wiring, road high pole lamp wire, ac rated voltage 250V and below DC voltage 500V and below, wire use temperature in-60℃ ~ + 80℃ in relative humidity in 98% environment can be normal. Use, mainly has the following advantages: 1, convenient tube. The diameter of the wire is fine, and the friction coefficient is significantly reduced when piercing the pipe.

2. Increase the wire-piercing capacity of the wire catheter. The wire diameter is small, for the same size of the catheter can be penetrated into the wire or large load flow.3, excellent wear resistance to reduce the damage to the insulation during wire pipe piercing and laying.

4, excellent hydrocarbon resistance, good chemical stability, that is, excellent oil resistance, liquefied gas and gas corrosion resistance, effectively improve the reliability and service life of the wire.

7, has the ability to withstand a considerable regular road current, 5 seconds short circuit to bear the temperature is higher than the ordinary PVC type. This is a nylon sheath, with a melting point of 215℃.

6, has the same flame retardant performance as PVC insulation. According to the relevant expert tests, the toxicity released by its combustion is much less than that of PE
