Characteristic

◆ Conductor: using multiple 0.08mm 4N grade anaerobic copper stranded

◆ Fill: cotton yarn ◆ coating layer: non-woven fabric

◆ Insulation: special mixed PVC material (monochrome code & color)

◆ Shielding: aluminum foil + tinned copper woven ◆ core number: 2~8 core

◆ External quilt: modified PVC material

◆ Conductor square number: 0.3 ~ 10 mm ²◆ outer color: orange

◆ Rated voltage: 600 / 1000V & 250V (control cable)

◆ Long-term permissible working temperature: fixed installation (-30~ + 105℃); mobile installation (-20~ + 105℃)

Minimum bending radius: fixed installation, bending radius of 6 D; moving installation, travel <10 m, bending radius is 10 D; travel 10 m, bending radius is 12 D

◆ Product characteristics: environmental protection, oil resistance, corrosion resistance, wear resistance, bending resistance, anti-interference (shielding type) and other characteristics are suitable for servo motor power system and power feedback system

 Testing

Test voltage: 3500V (power cable), 1200V (control cable)

Flexible test: moving speed simulation bending and moving conditions in the tow chain, fixed in the standard way, bending radius r=6D, s=600mm, speed =90 times / min; moving speed: overhead speed of 3 m/s, 2 m/s, sliding speed of 18 million insulation sheath performance detection: according to the material corresponding standard performance.
