Characteristic

◆ Conductor: using multiple 0.08mm 4N grade anaerobic copper stranded into ◆ insulation: mixed PVC material (monocolor code & color) ◆ core number: 4~40 cores

◆ Shielding: tin-plated copper weaving

◆ Number of conductor squares: 0.25~1.5mm²

◆ Core wire: 2 pairs of twisted + aluminum foil + braided shielding, all pairs of wire cables ◆ outer color: black (standing color)

◆ Rated voltage: 300 / 300V & 300 / 500V

◆ Long-term permissible working temperature: fixed installation (-30~ + 105℃); mobile installation (-20~ + 105℃)

◆ Minimum bending radius: fixed installation, bending radius is 6 D; moving installation, travel <10 m, bending radius is 7.5 D; travel 10 m, bending radius is 10 D

◆ Product characteristics: environmental protection, cold resistance, oil resistance, wear resistance, bending resistance, anti-interference (shielding type) and other characteristics are suitable for frequency converter, mechanical arm, mechanical track, lift, circulation dragging equipment and devices.

 Testing

Voltage test: 2000V / 5min (10A) (AC) & 1500V / 5min (10A) (AC)

Flexible test: moving speed simulation bending and moving conditions in the tow chain, fixed in the standard way, bending radius F=6D, s = 600,00 mm, speed =90 times / min; moving speed: overhead speed 3 m/s, sliding speed 2 m/s, more than 18 million times. Insulation sheath performance test: according to the corresponding standard performance of the material.
